B2000P Diagnostic Wheel Balancing System


Made In The USA

Add to cart

Request a call

Click to see additional Options / Models / Accessories Available


The B2000P is the only automated diagnostic wheel balancing system that offers touchless measurement and analysis. Automatic inputs remove the chance for error and inaccurate results. When combined with precise wheel balancing, the Runout Force Vectoring (RFV) diagnostics assure uniformity based total ride quality.



  • Patented Automatic Power Clamp - The electromechanical power clamp device always clamps the wheel accurately with a constant force and provides a reliable and consistent condition to assure accurate and repeatable measurements.
  • Touchscreen User Interface - Optical touchscreen ensures usability even when technicians are wearing gloves.
  • Runout Measurement - Hundreds of thousands of measurement points are taken with a resolution of 0.004"(0.1mm) to create a 3D model of the tire and wheel assembly.
  • Laser Based Runout - Quickly and easily provides advanced geometry related measurements, using technology that surpases the performance of mechanical roller-based systems.
  • Automatic 3D Tire Laser Mapping System - High resolution camera and laser based topography mapping emmulates the same technology used by tire manufacturers in industrial applications. Tire tread and sidewall color analysis allows depth, wear and abnormali
  • Automatic Inputs - Optical Scanners automatically measure the wheel. The scanners recognize the wheel type/edge. Correct weight type and size shown to aid productivity.
  • Automatic Balance Measurements - The color display shows the location of any imbalance and identifies the optimal tape or clip-on weight location. Also automatically measures assembly and rim runout and calculates runout force vectoring for a quick fix ma
  • Automatic Behind the Spoke Weight Placement - A laser indicates the exact weight location behind the spoke.
  • Opti-Line - Software improves ride performance and pull problems that cannot be fixed by wheel alignment alone. Helps eliminate multiple tire rotations to reposition tires and reduces time required for road tests. Hands any kind of wheel, including wheels



Wheel weight, max. 154 lbs
Weight approx. 418 lbs
Rim diameter 44 inch
Rim width 20 inch
Color Red
Power supply 230 / 50-60 1Ph V/Hz/A
Balancing accuracy 1 g
Balancing speed 200 rpm
Dimensions (L x W x H) 51.7 x 34.2 x 72.2 inch
